RE06M25W2N1KW
Prop. Pressure Relief Valve
Produktnummer: 30269
EAN: PRE06M25W2N1KW
Lagerbeholdning:
inkl. mva.
Parker's direct operated proportional pressure relief valve series RE06M*W provides a fast response time and low presssure drop due to its powerful solenoid.
Direct operated proportional pressure relief valves of the series RE06M*W ensure fast response times and a very low pressure drop. Thus they are typically used as remote control valves for flow rates below 3 l/min.
Markets:
• Industrial
Features/Benefits:
• Fast response time and low pressure drop - ensure efficient operation
• Very low pressure adjustment of pmin - predestined as remote control valve for cartridge valve combinations or pumps
• Short delivery time for most versions - no warehousing necessary
• Subplate mounting according to ISO 6264
• Direct operated with proportional solenoid
• 4 pressure stages
• 2 pressure ports, A and P
Applications:
• Suitable for general hydraulic applications
Function:
When the pressure in port P or A exeeds the pressure setting at the solenoid, the cone opens to port T and limits the pressure in port P to the adjusted level. The optimum performance can be achieved in combination with the digital amplifier module PCD00A-400. Also available as sandwich valve, see pilot valves series RPDM.
Markets:
• Industrial
Features/Benefits:
• Fast response time and low pressure drop - ensure efficient operation
• Very low pressure adjustment of pmin - predestined as remote control valve for cartridge valve combinations or pumps
• Short delivery time for most versions - no warehousing necessary
• Subplate mounting according to ISO 6264
• Direct operated with proportional solenoid
• 4 pressure stages
• 2 pressure ports, A and P
Applications:
• Suitable for general hydraulic applications
Function:
When the pressure in port P or A exeeds the pressure setting at the solenoid, the cone opens to port T and limits the pressure in port P to the adjusted level. The optimum performance can be achieved in combination with the digital amplifier module PCD00A-400. Also available as sandwich valve, see pilot valves series RPDM.
| Parker def attributter | |
|---|---|
| Merking | Standard |
| Magnetventil alternativ | 12 V / 2.5 A |
| Trykk kontrollområde | 250 bar |
| Tetningsmateriale | NBR |
| Parker desc attributter | |
|---|---|
| Port type | 2 pressure ports, A and P |
| Monteringsposisjon | Unrestricted, horizontal mounting preferred |
| Elektronikktype | External |
| Tetningsmateriale | NBR |
| Kropp materiale | Cast iron |
| For væske type | Hydraulic oil according to DIN 51524 |
| Maksimal driftstemperatur | 60 °C |
| Monteringstype | Subplate mounting |
| Produkt serie | Pressure valve |
| Maksimalt driftstrykk | 350 bar |
| Vekt | 1.8 kg |
| Minimum driftstemperatur | -20 °C |
| Maksimal strømningshastighet | 2.5 L/min |
| Trykk kontrollområde | 250 bar |
| Aktiveringstype | Solenoid, proportional |
| Grensesnittype | ISO 6264 norm |
| Driftstype | Direct |
| Port tilkobling | NG06 / CETOP 03 |
| Divisjon Kun fasettert | Hydraulic Valve Systems Division Europe |
| Parker | |
|---|---|
| Eske antall | 1.0000 |
| Beskrivelse | RE06M25W2N1KW20 PROP. PRESSURE RELIEF VALVE |
| Produktserie navn | Direct Operated Proportional Pressure Relief Valve - Series RE06M*W |
| Opprinnelsesland | DE |
| Toll kode | 84812010 |
| Vekt | 1.8000 |
| Vekt måleenhet | KG |
