D4S10-9C2344CDG0QB1
D4S10-9C2344CDG0QB1 Poppet Valve
Produktnummer: 24049
EAN: PD4S10-9C2344CDG0QB1
Lagerbeholdning:
inkl. mva.
D4S10-9C2344CDG0QB1
Parker's highly versatile 2/2-way seat valves series D4S10 for subplate mounting are designed for directional control functions allows to design individual hydraulic solutions for nominal flow up to 600 l/min.
Markets:
• Industrial
Features/Benefits:
• Proven, robust design - ensures reliable operation
• Individual configurability, various function options - useable for numerous applications
• Good price-performance ratio - fast return of investment
• Short delivery time - no warehousing necessary
• Subplate mounting according to ISO 5781
• Leak-free seat valve design
• Suitable for general hydraulic applications
Markets:
• Industrial
Features/Benefits:
• Proven, robust design - ensures reliable operation
• Individual configurability, various function options - useable for numerous applications
• Good price-performance ratio - fast return of investment
• Short delivery time - no warehousing necessary
• Subplate mounting according to ISO 5781
• Leak-free seat valve design
• Suitable for general hydraulic applications
| Parker def attributter | |
|---|---|
| Port tilkobling | NG32 / ISO 6264 |
| Hylse type | AA=0.60 AC, AB=0.40 AC |
| Minimum åpningstrykk | A-B 3.5 bar, B-A 6.0 bar |
| Koblingsalternativ | Shuttle valve X-Y and vent function: Solenoid activated, unpressurized circulation, with manual override |
| Pilot innløp avløps steder | Pilot line body: Internal from A+B (A-X orifice 1.2 / B-Y orifice 1.2) |
| Spole type | Poppet with closed bottom, 45° chamfer |
| Inngangsspenning | 24 (VDC) |
| Alternativer | na |
| Tetningsmateriale | NBR |
| Deksel | Pilot line cap: With vent function, external pilot drain from cap, X open, Y open, Z orifice 1.2, X-Y closed, Y1 open, VV01 closed |
| Parker desc attributter | |
|---|---|
| Monteringsposisjon | Unrestricted |
| Tetningsmateriale | NBR |
| Kropp materiale | Cast Iron |
| For væske type | Hydraulic Oil According to DIN 51524 |
| Maksimal driftstemperatur | 60 °C |
| Funksjon | Shuttle Valve X-Y |
| Monteringstype | Subplate |
| Produkt serie | Check Valve |
| Maksimalt driftstrykk | 350 bar |
| Vekt | 6 kg |
| Minimum driftstemperatur | -20 °C |
| Maksimal strømningshastighet | 600 L/min |
| Aktiveringstype | Pilot |
| Divisjon Kun fasettert | Hydraulic Valve Systems Division Europe |
| Parker | |
|---|---|
| Eske antall | 1.0000 |
| Beskrivelse | D4S10-9C2344CDG0QB1 POPPET VALVE |
| Produktserie navn | 2/2-Way Seat Valve for Subplate Mounting - Series D4S |
| Opprinnelsesland | DE |
| Toll kode | 84812010 |
| Vekt | 6.0000 |
| Vekt måleenhet | KG |
